Universal FireStopping Sealant UFS
Universal firestopping sealant which is suitable for metallic, non-metallic services and construction joints
Applications
- Metallic services: steel and cast iron 20“ (500 mm) - copper 6“ (150 mm)
- Non metallic service: PVC 2“ (51 mm open) 3“ (75 mm closed)
- Insulated service: 20“ (500 mm)
- Construction joints: 4“ (100 mm)
- HVAC 100“ (2500 mm)
- Cable bunches 4“ (100 mm): busway 27“ (686)
Advantages
- Water based
- Flexible set
- Contains mould growth inhibitor
- Freeze - thaw capabilities
- Paintable
- Accelerated age and humidity tested
- Low VOC
- Excellent acoustic properties
Get a Quote
Need more help?
8856000000
Building materials
How it works
Functioning
TECHNICAL DATA
Item no. | Languages on the cartridge | Contents [ml] | Contents [l] | Adapted for | Sales unit [pcs] | |
Item | ||||||
UFS 310 | 5165381) | DE, FR, EN, NL | 310 | – | – | 12 |
UFS 19 liter bucket | 533889 | – | – | 19 | – | 1 |
KPM 2 Plus | 053117 | – | – | – | FiAM 310, FFRS 310, UFS 310, FiGM 310 | 1 |
1) Curing rate is dependant on substrate, air humidity and weather conditions.Movement capability depends on UL listed system and configuration.
TECHNICAL DATA
Base material | Water-based elastomeric |
Density | approx. 1.31 g/cm³ |
Skin-forming time | approx. 20 – 30 min |
Curing rate | approx. 4 mm in 72 hours |
Storage temperature | + 2 °C to + 49 °C |
Movement capability | up to 50 % |
Intumescent activation | 190 °C to 593 °C °C |
Shelf life | up to 36 month |
pH Value | 6.5 – 7 |
Surface burning characteristics | Flame spread: 0 – Smoke: 0 |
Colour | red |
Curing rate is dependant on substrate, air humidity and weather conditions. Movement capability depends on UL listed system and configuration.
Application data
Services | Fire ratings (minutes) | ||
Types | Sizes | Integrated rating | Insulation rating |
PVC/CPVC closed pipe systems | 3″ (75 mm) | 120 | 120 |
PVC/CPVC open pipe systems | 2″ (50 mm) | 120 | 120 |
Steel and cast iron pipes | 20″ (508 mm) | 180 | 0 |
Copper pipes | 6″ (152 mm) | 180 | 0 |
Insulated services | 20″ (508 mm) | 120 | 120 |
Construction joints | 4″ (100 mm) | 120 | 120 |
HVAC | 100″ (2,500 mm) | 120 | 120 |
Cable bunches | 4″ (100 mm) | 120 | 120 |
Cable tray/ladder | 24″ (600 mm) | 120 | 45 |
Bus tar | 27″ (686 mm) | 120 | 45 |
For detailed information please refer to listed system.
